touchTymp MI 24

touchTymp MI 24

Model

MI 24

HSN CODE

90192010

ean upc code

N.A.

headset_mic Enquire
mail Share by email

touchTymp MI 24

  • Provides test results within seconds
  • Allows testing from infants to adults
  • Customizable to suit individual needs
  • Full 10.4'' touch-based interface for an intuitive handling
  • Innovative probe lights allow patient-focused operation
  • Probe tone 226 Hz, optional high frequency probe tone 1 kHz
  • Acoustic reflex frequencies 500 Hz, 1 kHz, 2 kHz, 4 kHz (ipsi- and optional contralateral)
  • High resolution and quick screen transitions
  • Built-in printer

Standard Accessories

Pen Probe, built-in calibration cavity, Sanibel ear tip kit, built-in printer and roll of thermal paper, mains cable, probe floss kit, MAICO USB flash drive kit, Impedance Module software, USB-cable, cleaning cloth, touchpen

Optional Accessories

Contralateral phones: DD45 C, CIR22, IP30

specifications
  • Height - 14.8 cm
  • Weight - 3.2 kg
  • Breadth - 34.5 cm
  • Length - 30 cm
  • Probe Frequency and Intensity - 226 Hz ± 1 %, 85 dBSPL (69 dBHL) ± 1.5 dB
  • Optional High Frequency - 1 kHz ± 1%, 69 dBSPL (69 dBHL) ± 1.5 dB
  • Pressure Range - -400 to +200 daPa
  • Accuracy of Measurement - ± 5 % or 0.1 ml
  • Volume Range - 0.1 to 8.0 ml
  • Tymp Compliance Range - 0.1 to 8.0 ml at 226 Hz 0.1 to 15.0 mmho at 1000 Hz
Enquire directly with MAICO Diagnostics GmbH and their authorized dealers on the platform in India.
